hansgrohe LogisSingle lever basin mixer 110 Fine with pop-up waste set











Model no. 71251000
Please try again.
Article features
- consists of: single lever basin mixer, waste set
- ComfortZone 110
- projection: 121 mm
- spout height: 110 mm
- spray type: normal spray
- maximum flow rate at 3 bar: 5 l/min
- ceramic cartridge
- temperature limitation adjustable
- suitable for continuous flow water heaters
- pop-up waste set G 1¼
- material waste set: synthetic
- connection type: G ⅜ connections
- connection dimension: DN15
Downloads
Installation information
Information
Please always observe the safety and installation information for your product. You find these details within the assembly instructions.Spare parts for build year 05/21
To the spare parts catalogItem no. | DescriptionArticle no.Description and article no. |
---|
1 | handle94376000 |
2 | screw cover96338000 |
3 | flange98863000 |
4 | nut98864000 |
5 | O-ring 24x298388000 |
6 | cartridge, assy97685000 |
7 | locking screw for handle95140000 |
8 | seal98865000 |
9 | adapter for cartridge98866000 |
10 | O-ring 23x298398000 |
11 | aerator M24x1 (5 l/min)94364000 |
12 | O-ring 30x1,598433000 |
13 | escutcheon94382000 |
14 | flat seal98749000 |
15 | fixing set (Ø 32)13961000 |
16 | lever collar97548000 |
17 | pull rod96657000 |
18 | connection hose 450 mm M8x0,75 G3/897206000 |
19 | O-ring 6,6x1,693019000 |
20 | pop up waste92168000 |
21 | fixation extension 35 mm13898000 |
Innovative technologies
AirPower: More volume due to air admixture
ComfortZone: Variable height fittings
EcoSmart: Save water and energy
AirPower
AirPower: More volume due to air admixture
Mixes water generously with air. The enriched drops are luscious, light and soothing on the skin and fall back in the washbasin with less splashing. The invaluable water resource is used more efficiently.
ComfortZone
ComfortZone: Variable height fittings
Greater freedom of movement when washing hands and hair or filling containers: The more precise the fit of the tap, the greater the convenience in the daily use of water. We call this individual use space between the tap and the ceramics the ComfortZone.
EcoSmart
EcoSmart: Save water and energy
This tap consumes only 5 l/min - significantly less water than conventional taps. And without any compromise on comfort. Since much less water needs to be heated, it also reduces energy costs. Very resource-friendly!
Impressions



Five-year manufacturer’s guarantee
5
year manufacturer's guarantee
Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
