hansgrohe Talis E
4-hole rim mounted bath mixer

product.image.alt
 View in AR
 360° view
Finish Brushed Black Chrome

Model no. 71748340

Article features

  • consists of: 4-hole rim mounted bath mixer, hand shower
  • 2 functions
  • projection: 196 mm
  • maximum pull-out length of hand shower: 1.60 m
  • maximum flow rate at 3 bar: 23,8 l/min
  • flow rate for bath spout at 3 bar: 23,8 l/min
  • flow rate of hand shower at 3 bar: 16,7 l/min
  • non-return valve
  • connection dimension: DN15
  • installation on bath rim
  • min. operating pressure: 1 bar

Downloads

Planning data

Download all Planning data files

Technical drawings

Download all Technical drawings files

Instructions

Download all Instructions files
Download all files

Installation information

Scale drawing

Download all files

Information

Please always observe the safety and installation information for your product. You find these details within the assembly instructions.
Information
Please note that other products are required to install the product.

Required parts

Basic set for 4-hole rim mounted bath mixer
hansgrohe

Basic set for 4-hole rim mounted bath mixer

Spare parts for build year 07/19

To the spare parts catalog
To the spare parts catalog
product.spareparts.image.alt
Item no. DescriptionArticle no.Description and article no.
b Grease90920000
a concealed item13244180
1 spout cpl.92780340
2 aerator M24x1 (25 l/min)92512340
3 diverter knob98707340
4 hollow set screw M6x697660000
5 O-ring 41x1,598168000
6 escutcheon Ø 70 mm97779340
7 O-ring 58x398202000
8 selector assy96775000
9 O-Ring 23x2,598183000
10 O-Ring 22x298185000
11 O-Ring 14x2,598189000
12 O-ring 9x2,598217000
13 handle92779340
14 handle fixing set94184000
15 set of color-rings cold / hot water95819000
16 escutcheon31098340
17 flat seal98749000
19 filter insert97708000
20 shower holder28071340
21 set of non return valves DW 1594074000
22 escutcheon Ø 52 mm97159340

Innovative technologies

More pleasure, more efficiency

Mixes generous quantities of air into the water. The enriched droplets are luxurious, light and soothing on the skin and cause less splash in the wash basin. For a more efficient use of the precious resource that is water.

Less limescale, more joy

Who actually likes cleaning? Limescale deposits and dirt disappear in an instant with this technology. Simply rub the flexible silicone discs or nozzles with a finger. It’s fast and keeps cleaning to a minimum.

AirPower

More pleasure, more efficiency

Mixes generous quantities of air into the water. The enriched droplets are luxurious, light and soothing on the skin and cause less splash in the wash basin. For a more efficient use of the precious resource that is water.

QuickClean

Less limescale, more joy

Who actually likes cleaning? Limescale deposits and dirt disappear in an instant with this technology. Simply rub the flexible silicone discs or nozzles with a finger. It’s fast and keeps cleaning to a minimum.

Awards

iF product design award 2019

 Everything from cars to toothbrushes: products that receive this award rank among the best-designed products in the world. Globally recognised seal of quality, awarded by the International Forum Design since 1953.

Five-year manufacturer’s guarantee

5

year manufacturer's guarantee

 Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
We endeavour to always provide up-to-date, complete information on our website. However, we do not assume any liability for the suitability of the information for particular uses.
