hansgrohe RainSelectThermostat for concealed installation for 2 functions with integrated shower holder
Model no. 15355000
Please try again.
Article features
- consists of: Thermostat, shower holder
- 2 functions
- simultaneous use of several outlets
- Select push-button on/off control for 2 outlets
- depending on volume flow and installation situation approx. 50% flow rate reduction and integrated shut off function
- thermostat cartridge, Start/stop valve to operate the functions
- flow rate per outlet: 26 l/min
- flow rate by simultaneous use of all outlets: 38 l/min
- maximum flow rate at 3 bar: 38 l/min
- min. operating pressure: 1 bar
- max. operating pressure: 10 bar
- Safety stop at 40 °C
- temperature limitation adjustable
- non-return valve
- for shower hoses with a conical nut
- connection type: basic set
- thermostat is delivered with buttons Rain large and hand shower
Downloads
Planning data
BIM data
Technical drawings
Installation information
Information
Please always observe the safety and installation information for your product. You find these details within the assembly instructions.Information
Find the right spare part
RainSelect Thermostat for concealed installation for 2 functions with integrated shower holderInnovative technologies
Intuitive jet adjustment
Safety lock at over 40 °C
Always constant water temperature
For mindful use of water
Select
Intuitive jet adjustment
The Select push button simplifies daily bathroom routines, as one simple push is all it takes for water to flow or stop. When showering, the user-friendly button can change the spray type or switch from the overhead to the hand shower.
SafetyStop
Safety lock at over 40 °C
A temperature limitation that ensures safe showering pleasure at all times. The function prevents too hot water from coming out of the shower. The scald protection is a big safety plus, especially for children or people with restricted mobility.
Thermostat
Always constant water temperature
Safe and reliable: The thermostat with integrated temperature control continuously monitors the water temperature while showering or bathing. It reacts quickly to changes in pressure and keeps the temperature comfortably at a constant level. For pleasant water enjoyment at all times.
Water flow control
For mindful use of water
The amount of water can be precisely adjusted via a control dial on the water-saving thermostat control, enabling you to use less water every day. Ideal also for children, who usually prefer gentle flow of water anyway.
