hansgrohe Raindance EShowerpipe 300 1jet with ShowerTablet 350

Model no. 27361000
Please try again.
Article features
- consists of: overhead shower, hand shower, shower thermostat, shower hose, slider, shower bar
- overhead shower Raindance E 300 Air 1jet
- shower head size overhead shower: 300 x 300 mm
- spray type overhead shower: RainAir
- ball-joint: overhead shower angle adjustable
- 90° position adjustable hand shower holder, pivots left and right, up and down
- spray type hand shower: RainAir, Rain, Whirl
- shelf finish: aluminium anodized
- bar width: 61 mm
- shower arm length overhead shower: 405 mm
- maximum flow rate at 3 bar: 16 l/min
- operating pressure: min. 1,5 bar/max. 10 bar
- CoolContact thermostat: Prevents the housing from heating up, making showering even safer
- thermostat ShowerTablet 350
- isolated water conduction
- safety lock at 40° C
- outlets controlled via turning handle
- will not run two outlets at same time
- installation type: exposed installation
- connection dimension DN15
- connection thread G ½
- centre distance 150 ± 12 mm
Downloads
BIM data
Technical drawings
Installation information
Information
Please always observe the safety and installation information for your product. You find these details within the assembly instructions.Optional accessories
Spare parts for build year 10/17
To the spare parts catalogItem no. | DescriptionArticle no.Description and article no. |
---|
1 | tile-matching-disk93146000 |
2 | mounting set96179800 |
3 | connecting thread93992000 |
4 | O-ring 10x1,598123000 |
5 | O-ring 6x298458000 |
6 | shower arm93221000 |
7 | screw93431000 |
8 | head shower93230000 |
9 | seal98058000 |
10 | air jet93127000 |
11 | filter93128000 |
12 | O-ring 15x298163000 |
13 | pipe with cover (950 mm)93222000 |
14 | O-ring 9x1,598117000 |
15 | support, assy93100000 |
16 | handshower26530000 |
17 | filter insert97708000 |
18 | shower hose Isiflex'B 1,60 m28276000 |
19 | connecting thread95392000 |
20 | O-ring 14x298129000 |
21 | hollow set screw M6x16 including o-ring 29x398372000 |
22 | handle93227000 |
23 | handle for shut off unit93226000 |
24 | handle fixing set93228000 |
25 | safety set93229000 |
26 | nut98913000 |
27 | thermostat cartridge98282000 |
28 | cartridge for exchanged connections92373000 |
29 | shut off unit with selector98283000 |
30 | cover93225000 |
31 | O-ring 76x2,598431000 |
32 | mounting kit98744000 |
33 | non return valve with filter93224000 |
34 | non return valve (pressure-resistant up to 2 MPa)93223000 |
35 | O-ring 16x298133000 |
36 | set of S-unions95772000 |
37 | noise reduction96429000 |
38 | O-ring 29x398371000 |
Innovative technologies

More pleasure, more efficiency
Products with this shower technology combined water with air to pamper you with more voluminous, lighter and softer water droplets on your skin. For greater showering pleasure with water efficiency.

Fast anti-limescale function
Who really likes cleaning? Our invention, QuickClean, rapidly removes dirt and limescale deposits from mixers and showers. Flexible silicon nubs make sure of this. Beware of copies: this QuickClean logo is the only guarantee of genuine Hansgrohe quality.

Great showering pleasure
You really need to experience this: great showering pleasure with jet types that has a feel-good factor. hansgrohe's hand and overhead showers, with a diameter of between 100 and 600 mm, envelop you in a real water dream – and ensure XXLPerformance in your bathroom.

Intuitive jet adjustment
Soft water droplets or an invigorating massage? Select the jet type you want in just one click, for even more showering fun.

CoolContact: safe and indulgent showering
Thermostatic mixers fitted with CoolContact cooling technology don’t get hot. The housing always stays nice and cool because the cold water inside it is directed straight to the surface. This can only mean one thing for you and your children: more safety in the bathroom.
AirPower

More pleasure, more efficiency
Products with this shower technology combined water with air to pamper you with more voluminous, lighter and softer water droplets on your skin. For greater showering pleasure with water efficiency.
QuickClean

Fast anti-limescale function
Who really likes cleaning? Our invention, QuickClean, rapidly removes dirt and limescale deposits from mixers and showers. Flexible silicon nubs make sure of this. Beware of copies: this QuickClean logo is the only guarantee of genuine Hansgrohe quality.
XXL Performance

Great showering pleasure
You really need to experience this: great showering pleasure with jet types that has a feel-good factor. hansgrohe's hand and overhead showers, with a diameter of between 100 and 600 mm, envelop you in a real water dream – and ensure XXLPerformance in your bathroom.
Select

Intuitive jet adjustment
Soft water droplets or an invigorating massage? Select the jet type you want in just one click, for even more showering fun.
CoolContact

CoolContact: safe and indulgent showering
Thermostatic mixers fitted with CoolContact cooling technology don’t get hot. The housing always stays nice and cool because the cold water inside it is directed straight to the surface. This can only mean one thing for you and your children: more safety in the bathroom.
Spray Types
RainAir
Gentle air-enriched rainfall.

Rain
Perfect for rinsing shampoo out of your hair.

Whirl
Concentrated targeted massage spray.
