hansgrohe MetropolSingle lever basin mixer 110 with lever handle and push-open waste set

Model no. 32507000
Please try again.
Article features
- consists of: single lever basin mixer, waste set
- ComfortZone 110
- projection 135 mm
- spray type: normal spray
- flow rate at 3 bar: 5 l/min
- ceramic cartridge
- temperature limitation adjustable
- suitable for continuous flow water heaters
- push-open waste set G 1¼
- material waste set: metal
- connection type: G ⅜ connections
- connection dimension: DN15
Downloads
BIM data
Technical drawings
Installation information
Information
Please always observe the safety and installation information for your product. You find these details within the assembly instructions.Spare parts for build year 01/17
To the spare parts catalogItem no. | DescriptionArticle no.Description and article no. |
---|
b | fixation extension 35 mm13898000 |
a | push-open waste set50100000 |
1 | handle92995000 |
2 | screw cover95704000 |
3 | flange92625000 |
4 | nut92689000 |
5 | O-ring 27x1,592527000 |
6 | O-ring 25x1,598146000 |
7 | cartridge, assy97685000 |
8 | seal98865000 |
9 | adapter for cartridge92628000 |
10 | adapter for cartridge98866000 |
11 | O-ring 23x298398000 |
12 | aerator M24x1 (5 l/min)92996000 |
13 | service tool95661000 |
14 | O-ring 32x1,592936000 |
15 | escutcheon93048000 |
16 | fixing set (Ø 32)13961000 |
17 | flat seal98749000 |
18 | lever collar97548000 |
19 | connection hose 600 mm M8x0,75 G3/896556000 |
20 | O-ring 6,6x1,693019000 |
21 | sealing set95581000 |
Innovative technologies

More pleasure, more efficiency
Products with this shower technology combined water with air to pamper you with more voluminous, lighter and softer water droplets on your skin. For greater showering pleasure with water efficiency.

Excellent user comfort
Generous proportions, sophisticated technology, intuitive operation. Outstanding design, high safety standards and considerably enhanced comfort: Hansgrohe showers, mixers and thermostats with this trademark extend your ComfortZone.

Save water, protect the climate
Hansgrohe mixers and showers, which are fitted with EcoSmart technology, require up to 60% less water than conventional products – without any loss of comfort. This means you can reduce your water and energy costs and conserve valuable resources.

Fast anti-limescale function
Who really likes cleaning? Our invention, QuickClean, rapidly removes dirt and limescale deposits from mixers and showers. Flexible silicon nubs make sure of this. Beware of copies: this QuickClean logo is the only guarantee of genuine Hansgrohe quality.
AirPower

More pleasure, more efficiency
Products with this shower technology combined water with air to pamper you with more voluminous, lighter and softer water droplets on your skin. For greater showering pleasure with water efficiency.
ComfortZone

Excellent user comfort
Generous proportions, sophisticated technology, intuitive operation. Outstanding design, high safety standards and considerably enhanced comfort: Hansgrohe showers, mixers and thermostats with this trademark extend your ComfortZone.
EcoSmart

Save water, protect the climate
Hansgrohe mixers and showers, which are fitted with EcoSmart technology, require up to 60% less water than conventional products – without any loss of comfort. This means you can reduce your water and energy costs and conserve valuable resources.
QuickClean

Fast anti-limescale function
Who really likes cleaning? Our invention, QuickClean, rapidly removes dirt and limescale deposits from mixers and showers. Flexible silicon nubs make sure of this. Beware of copies: this QuickClean logo is the only guarantee of genuine Hansgrohe quality.
