hansgrohe Ecostat EBath thermostat for exposed installation
Model no. 15774000
Please try again.
Article features
- projection 183 mm
- 2 functions
- CoolContact thermostat: Prevents the housing from heating up, making showering even safer
- thermostat cartridge
- maximum flow rate at 3 bar: 18,6 l/min
- flow rate for bath spout at 3 bar: 18,6 l/min
- flow rate of hand shower at 3 bar: 15,4 l/min
- min. operating pressure: 1 bar
- max. operating pressure: 10 bar
- Safety stop at 40 °C
- temperature limitation adjustable
- non-return valve
- protected against backflow, according to DIN EN 1717
- with silencer
- material handles: metal
- connection dimension: DN15
- connection type: s-shaped connections, G ½
- centre distance: 150 ± 12 mm
- dirt filter included
Downloads
Spare parts for build year 08/19
| Item no. |
|---|
| 1 | handle93521000 |
| 2 | handle fixing set93228000 |
| 3 | safety set93519000 |
| 4 | nut98913000 |
| 5 | shut off unit with selector98283000 |
| 6 | handle93520000 |
| 7 | pushbutton92848000 |
| 8 | thermostat cartridge98282000 |
| 9 | cartridge for exchanged connections92373000 |
| 10 | connecting thread95392000 |
| 11 | O-ring 14x298129000 |
| 12 | aerator M24x1 (38 l/min)95871000 |
| 13 | set of unions94285000 |
| 14 | set of nuts96157000 |
| 15 | non return valve (pressure-resistant up to 2 MPa)93136000 |
| 16 | non return valve96737000 |
| 17 | O-ring 17x1,598137000 |
| 18 | filter packing96922000 |
| 19 | escutcheon93518000 |
| 20 | set of S-unions (±12 mm)94140000 |
| 21 | noise reduction96429000 |
Innovative technologies
Safe and indulgent showering
For mindful use of water
Less limescale, more joy
Always constant water temperature
Safety lock at over 40 °C
CoolContact
Safe and indulgent showering
This thermostatic mixer is fitted with innovative cooling technology to prevent it from getting too hot, keeping it nice and cool to the touch. For care-free showering with no need to keep a safe distance or fear scalding.
Water flow control
For mindful use of water
The amount of water can be precisely adjusted via a control dial on the water-saving thermostat control, enabling you to use less water every day. Ideal also for children, who usually prefer gentle flow of water anyway.
QuickClean
Less limescale, more joy
Who actually likes cleaning? Limescale deposits and dirt disappear in an instant with this technology. Simply rub the flexible silicone discs or nozzles with a finger. It’s fast and keeps cleaning to a minimum.
Thermostat
Always constant water temperature
Safe and reliable: The thermostat with integrated temperature control continuously monitors the water temperature while showering or bathing. It reacts quickly to changes in pressure and keeps the temperature comfortably at a constant level. For pleasant water enjoyment at all times.
SafetyStop
Safety lock at over 40 °C
A temperature limitation that ensures safe showering pleasure at all times. The function prevents too hot water from coming out of the shower. The scald protection is a big safety plus, especially for children or people with restricted mobility.
