Complete set waste and overflow set for standard bath tubs

Complete set waste and overflow set for standard bath tubs
 View in AR
 360° view

Model no. 58316670

Article features

  • consists of: basic set, finish set
  • suitable for standard bath tubs
  • PE screw connection G 1½ x 40/ 50 mm
  • shortenable and flexible overflow hose
  • odour trap backwater height is 50 mm
  • bowden cable length 520 mm

Downloads

Planning data

Download all Planning data files

Technical drawings

Download all Technical drawings files

Instructions

Download all Instructions files
Download all files

Installation information

Scale drawing

Download all files

Information

Please always observe the safety and installation information for your product. You find these details within the assembly instructions.

Trust in highest quality

5

year manufacturer's guarantee

 Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
