hansgrohe
Basic set for single lever shower mixer for concealed installation

product.image.alt
 View in AR
 360° view

Model no. 13620180

Article features

  • connection dimension: DN15
  • ceramic cartridge
  • temperature limitation adjustable
  • minimum mounting depth: 55 mm
  • maximum mounting depth: 83 mm

Downloads

Planning data

Download all Planning data files

BIM data

Download all BIM data files

Technical drawings

Download all Technical drawings files

Instructions

Download all Instructions files
Download all files

Certificates

 An EPD is an Environmental Product Declaration. It is like an environmental identity card for products based on the results of a Life Cycle Assessment.

Installation information

Scale drawing

Download all files

Information

Please always observe the safety and installation information for your product. You find these details within the assembly instructions.

Spare parts for build year 06/18

To the spare parts catalog
To the spare parts catalog
product.spareparts.image.alt
Item no. DescriptionArticle no.Description and article no.
1 hollow screw96065000
2 nut95007000
3 O-ring 43x1,598148000
4 cartridge, assy92730000
5 locking screw for handle95140000
6 seal95008000
7 extension set 28 mm shower mixer32698000
8 O-ring 12x1,598430000
9 O-ring 10x1,598123000

Five-year manufacturer’s guarantee

5

year manufacturer's guarantee

 Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
