hansgrohe Rainfinity
Showerpipe 360 1jet with ShowerTablet 350

Showerpipe 360 1jet with ShowerTablet 350
 View in AR
 360° view
Change variant
hansgrohe Rainfinity
Select variant
Showerpipe 360 1jet with ShowerTablet 350
Showerpipe 250 1jet EcoSmart with ShowerTablet 350
Finish Matt White

Model no. 26853700

Article features

  • consists of: overhead shower, hand shower, shower thermostat, shower hose, slider, shower bar
  • overhead shower Rainfinity 360 1jet
  • shower head size overhead shower: 360 mm
  • spray type overhead shower: PowderRain
  • spray disc surface: graphite
  • surface shelf: graphite
  • flow rate PowderRain spray at 3 bar: 15,9 l/min
  • spray type hand shower: PowderRain, Intense PowderRain, MonoRain
  • flow rate of hand shower at 3 bar: 12,9 l/min
  • maximum flow rate for Showerpipe at 3 bar: 15,9 l/min
  • minimum flow pressure: 2 bar
  • max. operating pressure: 10 bar
  • ball-joint: overhead shower angle adjustable
  • pivots left and right, up and down, adjustable slider
  • CoolContact thermostat: Prevents the housing from heating up, making showering even safer
  • thermostat ShowerTablet 350
  • SafetyStop at 40°C
  • adjustable hot water limitation
  • outlets controlled via turning handle
  • will not run two functions at same time
  • suitable for continuous flow water heaters
  • mounting type: exposed installation
  • connection dimension: DN15
  • connection thread: G ½
  • centre distance: 150 ± 12 mm
  • intrinsically safe against backflow
  • bar width: 61 mm
  • 2 functions
  • material front of thermostat and pipe: safety glass

Downloads

Planning data

Download all Planning data files

BIM data

Download all BIM data files

Technical drawings

Download all Technical drawings files

Instructions

Download all Instructions files
Download all files

Installation information

Scale drawing

Installation example

Download all files

Information

Please always observe the safety and installation information for your product. You find these details within the assembly instructions.

Find the right spare part

Rainfinity Showerpipe 360 1jet with ShowerTablet 350
+
_
{{part.number}}
{{part.text}} Art. no.  {{part.articleNumber}}

Innovative technologies

Safe and indulgent showering

This thermostatic mixer is fitted with innovative cooling technology to prevent it from getting too hot, keeping it nice and cool to the touch. For care-free showering with no need to keep a safe distance or fear scalding.

Intuitive jet adjustment

The Select push button simplifies daily bathroom routines, as one simple push is all it takes for water to flow or stop. When showering, the user-friendly button can change the spray type or switch from the overhead to the hand shower.

Less limescale, more joy

Who actually likes cleaning? Limescale deposits and dirt disappear in an instant with this technology. Simply rub the flexible silicone discs or nozzles with a finger. It’s fast and keeps cleaning to a minimum.

Great showering pleasure

XXL showering indulgence that envelops the complete body in real-life dreams of water using wonderfully soothing spray types from hand showers and overhead showers with diameters of 100 to 600 mm.

CoolContact

Safe and indulgent showering

This thermostatic mixer is fitted with innovative cooling technology to prevent it from getting too hot, keeping it nice and cool to the touch. For care-free showering with no need to keep a safe distance or fear scalding.

Select

Intuitive jet adjustment

The Select push button simplifies daily bathroom routines, as one simple push is all it takes for water to flow or stop. When showering, the user-friendly button can change the spray type or switch from the overhead to the hand shower.

QuickClean

Less limescale, more joy

Who actually likes cleaning? Limescale deposits and dirt disappear in an instant with this technology. Simply rub the flexible silicone discs or nozzles with a finger. It’s fast and keeps cleaning to a minimum.

XXL Performance

Great showering pleasure

XXL showering indulgence that envelops the complete body in real-life dreams of water using wonderfully soothing spray types from hand showers and overhead showers with diameters of 100 to 600 mm.

Spray Types

Relaxing, micro-fine droplets that gently and quietly envelop the body. The water is transformed into a delicate cocoon that sensually embraces the body. For sensual showering and indulgent, deep relaxation.
Intense spray consisting of micro-fine droplets. The number of droplets is much higher for an extremely effective way to rinse out shampoo. The water feels velvety soft and ultra-lightweight on the skin, with very little splashback.
Focused and extremly gentle spray for feel-good wellness. The focused spray type is perfect for hydrotherapeutic showering and cold water treatments. For anyone who loves winding down in their shower or bath tub.

PowderRain

Relaxing, micro-fine droplets that gently and quietly envelop the body. The water is transformed into a delicate cocoon that sensually embraces the body. For sensual showering and indulgent, deep relaxation.

Intense PowderRain

Intense spray consisting of micro-fine droplets. The number of droplets is much higher for an extremely effective way to rinse out shampoo. The water feels velvety soft and ultra-lightweight on the skin, with very little splashback.

MonoRain

Focused and extremly gentle spray for feel-good wellness. The focused spray type is perfect for hydrotherapeutic showering and cold water treatments. For anyone who loves winding down in their shower or bath tub.

Trust in highest quality

5

year manufacturer's guarantee

 Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
