hansgrohe FocusElectronic basin mixer 130 with temperature control battery operation
Model no. 31171000
Please try again.
Article features
- ComfortZone 130
- projection: 127 mm
- spray type: normal spray
- maximum flow rate at 3 bar: 5 l/min
- temperature limitation adjustable
- temperature adjustable via mixer lever on the side
- non-return valve
- suitable for continous flow water heaters
- infrared sensor technology
- automatic environmental adjustment of infrared sensor
- adjustable optical range of infrared sensor (2 settings)
- battery condition indicator available
- battery operation 6V (lifetime approx. 2 years, battery included in scope of supply)
- running time: 10 s
- hygiene rinse activatable (automatic water flow)
- frequency of hygiene rinse: 24 h
- flushing time hygiene rinse: 10 s
- permanent rinse activatable (single water flow for 180 seconds, suitable for thermal disinfection)
- cleaning mode: manual water stop for washbasin cleaning
- connection dimension: DN15
- dirt filters in the connection hoses
- product listed in DGNB navigator
Downloads
Technical drawings
Innovative technologies
More pleasure, more efficiency
Saving resources with pleasure
Excellent user comfort
Starts the electronic tap
AirPower
More pleasure, more efficiency
Mixes generous quantities of air into the water. The enriched droplets are luxurious, light and soothing on the skin and cause less splash in the wash basin. For a more efficient use of the precious resource that is water.
EcoSmart
Saving resources with pleasure
Our standard taps are equipped with our EcoSmart technology to save water and energy. While enjoying the full water experience, it consumes max. 5 l/min thanks to a flow limiter. Good for a conscious consumption of water and energy.
ComfortZone
Excellent user comfort
More elbow room when washing hands, a comfortable way to wash hair or just fill containers: The better the tap fits the space, the more flexible the options become. We call the area between the tap and the ceramics the ComfortZone because you can use it however you like.
SensorActivation
Starts the electronic tap
The sensor on this contactless tap acts like a motion sensor as it responds to changes in the infrared rays. Water only flows once it detects warmth from hands. This is economical and environmentally friendly as well as contactless and hygienic.
