hansgrohe Activera S
Showerpipe 240 1jet EcoSmart with single lever mixer Varia

NEW
Showerpipe 240 1jet EcoSmart with single lever mixer Varia
product.closeup.image.alt
product.closeup.image.alt
1 / 3
 View in AR
 360° view
Finish Chrome

Model no. 28875000

Article features

  • consists of: shower bar, overhead shower, hand shower, slider, single lever shower mixer, shower hose
  • overhead shower Activera S 240 1jet
  • shower head size overhead shower: 240 mm
  • spray type overhead shower: Rain
  • spray disc surface: graphite
  • FlexPower: nozzles automatically adjust to water pressure by opening and closing
  • QuickClean+: avoid limescale deposits thanks to the elasticity of the nozzles
  • flow regulator: 8 l/min (with possible tolerances -20 %)
  • flow rate Rain spray at 3 bar: 7,8 l/min
  • spray type hand shower: Rain, ImpactRain
  • maximum flow rate of hand shower at 3 bar: 7,8 l/min
  • maximum flow rate for Showerpipe at 3 bar: 8 l/min
  • minimum flow pressure: 0,5 bar
  • max. operating pressure: 10 bar
  • ball-joint: overhead shower angle adjustable
  • convenient spray selection via Select button on the hand shower
  • variable wall support
  • variable drilling hole distance: 750 - 850 mm
  • pipe can be shortened in height
  • shower bar diameter: 22 mm
  • height-adjustable hand shower holder
  • shower arm length overhead shower: 350 mm
  • suitable for continuous flow water heaters with an output of 18 kW
  • mounting type: exposed installation
  • connection dimension: DN15
  • connection thread: G ½
  • centre distance: 150 ± 12 mm
  • ceramic cartridge
  • temperature limitation adjustable
  • 2 functions
  • EU taxonomy: max. 8 l/min - Do No Significant Harm (DNSH)
  • removable shower head
  • slider rotatable on the pipe for left or right operation

Downloads

Installation information

Scale drawing

Download all files

Information

Please always observe the safety and installation information for your product. You find these details within the assembly instructions.

Innovative technologies

Want to save water? With pleasure!

Enjoy shower pleasure using less water thanks to our EcoSmart technology. The products convince with a maximum flow rate of 8 l/min thanks to a flow limiter. Can help in reducing water and energy costs every day.

FlexPower - Top performance with less water

Innovative technology that provides great shower comfort with low consumption. Elastic nozzles in the shower head dynamically adapt to the water flow and pressure, increasing the performance of the spray and enabling more efficient use of water.

Effectively prevents annoying limescale buildup

Elastic silicone nozzles constantly open and close preventing limescale build-up. Innovative technology for long-lasting water enjoyment with less cleaning and maintenance.

Great showering pleasure

XXL showering indulgence that envelops the complete body in real-life dreams of water using wonderfully soothing spray types from hand showers and overhead showers with diameters of 100 to 600 mm.

Intuitive jet adjustment

The Select push button simplifies daily bathroom routines, as one simple push is all it takes for water to flow or stop. When showering, the user-friendly button can change the spray type or switch from the overhead to the hand shower.

Flexible mounting with variable wall support.

The flexible wall support allows the use of existing drill holes and individual installation of shower bars. Ideal for easy shower and bathtub renovations.

Angle-adjustable overhead shower

The angle of the overhead shower can be tilted so that the shower rain is adjusted to suit the specific shower area or a person’s height. The water sprays can then work their feel-good magic and envelop the whole body.

EcoSmart

Want to save water? With pleasure!

Enjoy shower pleasure using less water thanks to our EcoSmart technology. The products convince with a maximum flow rate of 8 l/min thanks to a flow limiter. Can help in reducing water and energy costs every day.

FlexPower

FlexPower - Top performance with less water

Innovative technology that provides great shower comfort with low consumption. Elastic nozzles in the shower head dynamically adapt to the water flow and pressure, increasing the performance of the spray and enabling more efficient use of water.

QuickClean+

Effectively prevents annoying limescale buildup

Elastic silicone nozzles constantly open and close preventing limescale build-up. Innovative technology for long-lasting water enjoyment with less cleaning and maintenance.

XXL Performance

Great showering pleasure

XXL showering indulgence that envelops the complete body in real-life dreams of water using wonderfully soothing spray types from hand showers and overhead showers with diameters of 100 to 600 mm.

Select

Intuitive jet adjustment

The Select push button simplifies daily bathroom routines, as one simple push is all it takes for water to flow or stop. When showering, the user-friendly button can change the spray type or switch from the overhead to the hand shower.

VarioFix

Flexible mounting with variable wall support.

The flexible wall support allows the use of existing drill holes and individual installation of shower bars. Ideal for easy shower and bathtub renovations.

Adjustable Shower Head

Angle-adjustable overhead shower

The angle of the overhead shower can be tilted so that the shower rain is adjusted to suit the specific shower area or a person’s height. The water sprays can then work their feel-good magic and envelop the whole body.

Spray Types

Invigorating and energising everyday showering indulgence with a satisfyingly full shower rain. With its small outlets on the shower head, this spray type works efficiently to thoroughly rinse out shampoo.
Spray with an innovative structure creates an intense showering feeling from just a little water. Different zones in the spray provide different water intensities. Ideal for gentle massages or for rinsing out shampoo.
ImpactRain

Rain

Invigorating and energising everyday showering indulgence with a satisfyingly full shower rain. With its small outlets on the shower head, this spray type works efficiently to thoroughly rinse out shampoo.

ImpactRain

Spray with an innovative structure creates an intense showering feeling from just a little water. Different zones in the spray provide different water intensities. Ideal for gentle massages or for rinsing out shampoo.

ImpactRain

Trust in highest quality

5

year manufacturer's guarantee

 Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
We endeavour to always provide up-to-date, complete information on our website. However, we do not assume any liability for the suitability of the information for particular uses.
